Minimum Spanning Tree: Definition and Examples

Ever faced the challenge of connecting multiple points in the most efficient way possible? The solution lies in understanding the Minimum Spanning Tree (MST). But do you wonder how can it simplify complex networks? In this blog, we’ll delve into the definition and explore practical examples that highlight its significance.

Mastering this concept can revolutionise your approach to problem-solving in fields like Computer Science and Logistics. Read ahead to discover the transformative potential of the Minimum Spanning Tree.

Table of Contents

1) Understanding Spanning Tree

2) What is a Minimum Spanning Tree?

3) Example of a Spanning Tree

4) Algorithms to Find Minimum Spanning Tree

5) Applications of Minimum Spanning Tree

6) Conclusion

Understanding Spanning Tree

A Spanning Tree is a portion of a graph that includes all the vertices with the minimum number of edges. Multiple Spanning Trees can exist for a given graph, but there will always be at least one. In a Spanning Tree, the edges included are known as “branch edges,” while those excluded are “cycle edges.”

This type of graph helps determine the least number of edges needed to connect all vertices. It is also useful for creating minimally secured networks with redundant paths.

What is a Minimum Spanning Tree?

A Minimum Spanning Tree (MST) is a selection of edges from a connected, edge-weighted graph that connects all vertices without creating cycles and with the lowest possible total edge weight. It signifies the most cost-effective method to link a set of vertices.

In an MST, all edge weights must be unique. If the graph’s edge weights are identical, any Spanning Tree of the graph qualifies as an MST. The edges of the MST can be determined using the greedy algorithm or more advanced methods like Kruskal’s or Prim’s algorithms.

Example of a Spanning Tree

A Spanning Tree is a subgraph of an undirected, connected graph that includes all the vertices of the original graph with the minimum possible number of edges. Here’s a detailed example to illustrate this concept:

Consider a graph ( G ) with the following vertices and edges:

a) Vertices: ( A, B, C, D )

b) Edges: ( (A-B), (A-C), (B-C), (B-D), (C-D) )

The graph can be visualised as follows:


To create a Spanning Tree from this graph, we need to ensure that all vertices are connected with the minimum number of edges and without forming any cycles. One possible Spanning Tree for this graph could be:

a) Edges: ( (A-B), (B-C), (B-D) )

This can be visualised as:


In this Spanning Tree, all vertices ( A, B, C, D ) are connected, and there are no cycles. The total number of edges is ( 3 ), which is ( N-1 ), where ( N ) is the number of vertices.

Equip yourself with the latest coding techniques and tools - join our Programming Trainings now!

Algorithms to Find Minimum Spanning Tree

There are multiple algorithms available to determine the Minimum Spanning Tree from a given graph. Some of these include:

1) Kruskal's Algorithm for Finding Minimum Spanning Trees

It is one of the popular algorithms for figuring out the Minimum Spanning Tree in a connected, undirected graph. It is a greedy algorithm. The workflow of the algorithm is as follows:

a) First, it sorts every edge of the graph by its weights

b) Then, it begins the iterations to find the Spanning Tree

c) During each iteration, the algorithm sequentially adds the next lowest-weight edge, making sure that the chosen edges do not create a cycle.

This algorithm can be efficiently implemented using a Disjoint-Set (DSU) data structure to keep track of the connected components of the graph. It is used in various practical applications such as network design, clustering, and Data Analysis.

2) Prim's Algorithm for Minimum Spanning Trees

This is also a greedy algorithm with the following workflow:

a) It begins by choosing a random vertex and adding it to the MST

b) It then continuously looks for the smallest edge weight that links a vertex in the MST to one not yet included.

c) This procedure repeats until all vertices are part of the MST

To efficiently select the minimum weight edge at each iteration, this algorithm uses a priority queue to store the vertices sorted by their current minimum edge weight. It also keeps track of the MST using an array or another suitable data structure, depending on the data type being stored. It can be applied in scenarios like image segmentation and routing for finding the shortest path.

3) Boruvka's Algorithm for Minimum Spanning Trees

This is also a graph traversal algorithm applied to find the Minimum Spanning Tree of a connected, undirected graph. It is one of the oldest algorithms. The algorithm works by iteratively constructing the MST, with each vertex in the graph as its own tree.

In every iteration, the algorithm identifies the cheapest edge that connects one tree to another and sums up that edge to the Minimum Spanning Tree. This is quite similar to Prim’s algorithm for finding the MST. The algorithm follows this workflow:

1) Initialise a forest of trees, with every vertex in the graph as its own tree

2) For every tree in the forest:

a) Find the cheapest edge that links it to another tree

b) Add these edges to the Minimum Spanning Tree

3) Update the forest by combining the trees linked by the added edges

4) Repeat the above steps until the forest includes only one tree, which is the Minimum Spanning Tree.

Boruvka’s algorithm is a straightforward and easy-to-implement method for finding Minimum Spanning Trees, though it may not be as effective as other algorithms for large graphs with multiple edges.

Join our comprehensive Delphi Course and gain hands-on training in Software Development!

Applications of Minimum Spanning Tree

A Minimum Spanning Tree (MST) is a fundamental concept in graph theory with numerous practical applications across various fields. Here are some key applications:

a) MSTs are applied to design efficient and cost-effective networks, such as computer networks, telecommunications networks, and electrical grids. By connecting all nodes with the minimum total edge weight, MSTs help minimise the cost of laying cables or wires.

b) In Data Analysis and Machine Learning,  MSTs can be used for clustering. By removing the k-1 most expensive edges from an MST, the graph is divided into k clusters, which can be useful for grouping similar data points.

c) MSTs are used in approximation algorithms to solve NP-hard problems relevant to the Travelling Salesman Problem (TSP). An MST can provide a 2-approximation for the TSP, offering a solution that is within twice the optimal length.

d) In computer vision, MSTs are used for image segmentation. By treating pixels as nodes and the difference in pixel values as edge weights, an MST can help segment an image into different regions based on similarity.

e)  MSTs are used to construct phylogenetic trees, which represent the evolutionary relationships between different species. This helps in understanding the genetic linkage and evolutionary history of organisms.

f) MSTs are applied in GIS to create maps that minimise the total distance between various locations. This is useful for planning transportation routes, laying pipelines, and other logistical tasks.

g)  MSTs help determine the optimal location of facilities such as warehouses or power plants in a network. By minimising the total distance to all connected points, MSTs ensure efficient placement and reduced transportation costs.

h) In coding theory, MSTs are used in the design of Low-Density Parity-Check (LDPC) codes for error correction. These codes help in detecting and correcting errors in data transmission, ensuring reliable communication.

i) MSTs are used in network protocols to avoid cycles and ensure efficient data routing. The Spanning Tree Protocol (STP) in Ethernet networks uses MST principles to prevent loops and ensure a loop-free topology.

j)  In Physics, MSTs model the locality of particle interactions in turbulent fluid flows. This helps in understanding and simulating complex physical phenomena.

Conclusion

Understanding the Minimum Spanning Tree (MST) is crucial for anyone involved in fields such as computer science, logistics, and network design. By learning about MSTs and the algorithms used to find them, such as Kruskal's, Prim's, and Boruvka's, you can efficiently solve complex problems related to network optimisation, clustering, and data analysis.
